Camera
Resolution : Dual 2K+ Resolution
Image Sensor : 1/3″ Progressive Scan CMOS
Shutter Speed : Self-adaptive shutter
Fixed Lens : 2.8mm@F1.6 , view angle: 108°(Diagonal), 92° (Horizontal), 50°(Vertical)
PT Lens : 6mm@F1.6 , view angle: 60°(Diagonal), 51° (Horizontal), 28°(Vertical)
Lens Mount : M12
Day & Night : IR-cut filter with auto-switching
DNR : 3D DNR
WDR : Digital WDR
Compression
Video Compression : H.264/H.265
Video Bit Rate : Adaptive bit rate.
Network
Smart Alarm : Motion Detection, Human Shape Detection, Loud Noise Detection, Patrol Mode Detection
Wi-Fi Pairing : AP paring
Protocol : EZVIZ cloud proprietary protocol
Interface Protocol : EZVIZ cloud proprietary protocol
Max. Resolution : 2560 × 1440
Frame Rate : Max:30fps; Self-Adaptive during network transmission
Interface
Storage : Micro SD card slot (Max. 512G)
Power : TYPE-C
Wired Network : RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Wi-Fi
Standard : IEEE802.11a, IEEE802.11b, 802.11g, 802.11n,802.11ac 802.11ax
Frequency Range : 2.4GHz: 2.4 GHz ~ 2.4835 GHz 5GHz: 5.15GHz~5.25GHz
Security : WPA-PSK, WPA2-PSK, WPA3-Personal
General
Operating Conditions : -10°C to 45°C ( -14 °F to 113 °F ) Humidity 95% or less (non-condensing)
Power Consumption : 8W max
Power Supply : DC 5V/2A
IR Range : MAX. 10 meters (32.81ft)
Dimensions : 88 × 88 × 131.5 mm (3.46 × 3.47 ×4.69 in)
Package Dimensions : 200 ×105 ×105 mm (7.87 × 4.13 × 4.13 in)
Net Weight : 270 g (9.52 oz)
Bare Weight : 499 g (17.60 oz)
Isi kelengkapan:
* 1x Camera
* 1x Power Adapter
* 1x Power Cable
* 1x Drill Template
* 1x Mounting Plate
* 1 set Screw Kit
* Regulatory Information
* Quick Start Guide
